Fastening Methods That Matter in Product Design: Bolts & Nuts vs. Snap-Fits
Key Takeaways
- The two fastening methods you'll reach for most in product design are bolts/nuts and snap-fits.
- Bolts and nuts use separate hardware (a bolt, a nut, and sometimes a threaded insert), so they can be disassembled and reassembled repeatedly regardless of material. Snap-fits rely on the plastic part's own elastic deflection — no extra hardware, lower assembly cost, but how many times you can snap them together depends on the material's stress limits and the geometry (cantilever, annular, etc.).
- Use bolts and nuts when the part needs maintenance access, add a threaded insert when a plastic part needs repeated fastening, use a heli-coil to reinforce threads that have already worn, and go with a snap-fit when you want to cut assembly cost.
Your Fastening Method Determines How Well the Assembly Holds Up
It's a common story: a design assembles fine early on, and then months later the threads strip or a snap-fit hook cracks once the product's actually in use. Most of the time that's because the fastening method wasn't matched to how the product actually gets used — how often it's taken apart, what load it carries, what it's made of.
Choosing a fastening method means weighing material, part size and wall thickness, the motion of the joint, and tolerances. Whatever process makes your parts — injection molding, CNC machining, sheet metal fabrication, or 3D printing — you'll face the same decision at the assembly stage. This guide compares the two methods you'll use most often, bolts/nuts and snap-fits, and also covers threaded inserts and heli-coils, which come into play with bolts and nuts whenever a plastic part needs to be fastened repeatedly.
Fastening Method Comparison
| Criteria | Bolts & Nuts | Snap-Fits |
| Joining principle | Threaded fastening (add a threaded insert or heli-coil in plastic parts if wear resistance matters) | Elastic deflection of a plastic hook |
| Disassembly / reassembly | Yes | Depends on the design |
| Common materials | Metal or plastic | Plastic only |
| Assembly cost | Moderate (fastening labor) | Low (simple press-fit) |
| Best for | Parts that need maintenance or disassembly | Consumer products where cutting assembly cost matters |
Bolt and Nut Fastening
Bolt-and-nut fastening is the default choice in mechanical design. Two or more parts are joined with a screw and a nut for a connection that's simple and secure. It holds up well and it's easy to assemble and take apart, which is why it's used more than any other method.
- Through-bolts: A hole is drilled through both parts, the bolt passes all the way through, and a nut threads on from the other side.
- Tapped (self-tapping) bolts: One part gets a tapped hole — internal threads cut directly into it — and the bolt threads straight in. No nut needed.
- Stud bolts: Headless bolts threaded on both ends. One end screws into the part; a nut goes on the other end.
Thread Wear in Tapped Holes — and How Threaded Inserts and Heli-Coils Fix It
A tapped bolt relies on threads cut directly into the part. Creallo supports this tapping process on injection-molded, CNC-machined, and 3D-printed parts alike.
The problem shows up when the part is plastic. Threads cut straight into plastic aren't very strong, and repeated assembly and disassembly wears them down fast — resin materials like SLA can strip after just 3-5 cycles.
Threaded inserts and heli-coils both address this, and Creallo supports both processes.
- Threaded (heat-set) inserts: A metal insert — usually brass — gets embedded in the plastic housing, so the threads hold up under repeated fastening. Common in both injection-molded and 3D-printed parts. For insert sizing (M1-M8), hole design guidelines, and how inserts compare to straight tapping, see “Additional Options for 3D Printing and CNC Machining: Inserts & Tapping.”
- Heli-coils: A spring-shaped metal coil threads into the hole to reinforce threads that are worn or prone to wearing, most often used to reinforce threads in plastic/resin parts.
Snap-Fit Joints
A snap-fit is a fastening feature molded directly into a plastic part. It's simpler than other joining methods — the parts snap together with a single push, which keeps assembly cost down.
Common Types
- Cantilever: The most common type. A flexible arm deflects and catches on the mating feature. Cross-sections can be rectangular, tapered, U-shaped, or T-shaped.
- Annular: Wraps around a cylindrical part to snap into place — common on round lids and caps.
- Torsional: Uses the restoring torque from twisting a rod or shaft to hold the joint — used in rotating latches, connectors, and similar mechanisms.
FAQ
Q: Bolts and nuts, or a snap-fit — which should I choose?
If the part needs maintenance or disassembly, go with bolts and nuts. If you're building a plastic consumer product and want to cut assembly cost, a snap-fit is usually the better fit.
Q: When should I use a threaded insert?
Whenever plastic threads alone would wear out from repeated assembly and disassembly — covers, enclosures, anything that gets opened and closed regularly, or parts made from wear-prone resins like SLA.
Q: What's the biggest design risk with snap-fits?
Material stress limits and structural stiffness. If the wall is too thin, the hook can crack after repeated engagement and disengagement — it's worth having a molding engineer review the design.
